| Nominal Pipe Size | Actual Pipe Size | Sleeve | Link Seal Model | # Links Per Seal | |
|---|---|---|---|---|---|
| 1/2 | .840 | 2 | LS-200-C | 4 | |
| 3/4 | 2.000 | 2 | LS-200-C | 4 | |
| 1 | 2.005 | 2½ | LS-200-C | 5 | |
| 1-1/4 | 2.000 | 4 | LS-340-C | 5 | |
| 1-1/2 | 2.000 | 3 | LS-200-C | 6 | |
| 2 | 3.005 | 4 | LS-300-C | 6 | |
| 2-1/2 | 3.005 | 4 | LS-200-C | 9 | |
| 3 | 4.000 | 6 | LS-340-C | 9 | |
| 4 | 5.000 | 6 | LS-300-C | 10 | |
| 5 | 6.003 | 8 | LS-425-C | 6 | |
| 6 | 7.005 | 10 | LS-400-C | 7 | |
| 8 | 9.005 | 12 | LS-475-C | 12 | |
| 10 | 11.000 | 14 | LS-400-C | 10 | |
| 12 | 13.000 | 16 | LS-425-C | 12 | |
| 14 | 15.000 | 18 | LS-400-C | 13 | |
| 16 | 17.000 | 20 | LS-400-C | 15 | |
| 18 | 19.000 | 22 | LS-400-C | 17 | |
| 20 | 21.000 | 24 | LS-400-C | 18 |
